Custom Built MPI

AC Electromagnetic Yoke

For Further Information on Technical & Commercial Details, Kindly fill the Custom Built Information Sheet

MPI Checklist
Contact us for more details
SKU: Custom Built MPI Categories: , ,
Description

We have made custom built MPI Equipment for following applications

Automotive Application

Engine Components

  • Engine block and cylinder
  • Crankshafts
  • Connecting Rods
  • Pistons and Piston Pins
  • Rocker Arms
  • Rocker Shafts
  • Cylinder liners
  • Tappets
  • Engine Valves
  • Camshafts
  • Engine Valves

Transmission & Steering

  • Transmission Gears
  • Input & output shafts
  • Steering Shafts / Drive shafts
  • Tripots and CV joints, Tulips
  • Steering Knuckles
  • Stub Axles
  • Fly wheels
  • Rack bars & Shafts
  • Gears & pinions

Under Chassis & Structural

  • Front Axle Beams
  • Rear Axle shafts
  • Suspension Springs
  • Stabilizer Bars
  • Fasteners
  • Propeller shaft parts
  • Rear Axle & Differential Parts
  • Alloy Wheels

Aerospace Applications

  • Turbine Blades
  • Landing Gears
  • Aircrafts Structural Parts
  • Aerospace Engine Components

Oil & Gas Applications

  • Valves (Gate valves, Butterfly Valves, Pressure Relief Valves, Ball valves, Diaphragm Valves, Control Valves)
  • Valve Bodies
  • Dredging
  • OCGT
  • Drill Parts

View Videos on Past Projects

Please fill the form

ZChem expert will provide you product details

Please enable JavaScript in your browser to complete this form.
Name
Reviews (0)

Reviews

There are no reviews yet.

Be the first to review “Custom Built MPI”

Your email address will not be published. Required fields are marked *

Shipping & Delivery

Related products

ZChek 9E Black

, ,

Oil-Based Visible Magnetic Particle Suspension

ZChek-9E Black is a high performance Non-Fluorescent Black Magnetic Particle Powder suspended in the ZChek 801 Cart oil. ZChek 9E Black is used to detect Surface & near surface discontinuities in Ferro magnetic materials and its alloys. Will give best results when used in combination with Zchek WP white contrast paint.
Download TDS
Download MSDS
Batch Certificate
Contact us for more details
Read more

ZChek F9W

, ,

Wet Method Fluorescent Magnetic Particles

ZChek F9W is a Green Colored water based Magnetic Particle Powder designed to be fluorescing Bright Green under UV Light. ZChek F9W consists of high sensitivity particles for detection of very fine discontinuities in Ferromagnetic materials. Using the state-of-the-art encapsulation technology, ZChek F9W is manufactured to exhibit excellent properties (High permeability, low retentivity, high mobility and optimum particle distribution) required for high sensitive fluorescent MPI process. Special additives in F9W provide excellent particle mobility in water medium and avoid flash rusting of parts.
Download TDS
Download MSDS
Batch Certificate
Contact us for more details
Read more

ZC-9D

, , ,

AC/HWDC Electromagnetic Yoke

The light weight electromagnetic yoke is the ideal tool for detection of surface or sub-surface cracks and flaws in any ferromagnetic material. No other low cost, portable equipment offers such versatility in Magnetic Particle Inspection. Fast and simple to operate, it is widely used with either dry or wet method fluorescent or non – fluorescent magnetic powders, in the testing of welds, automotive or railroad components, machine parts, steel and grey iron castings, forgings and in plan inspection, maintenance and repair.
Download Brochure
Contact us for more details

Technical Specifications

  • Input supply – 220V, 50Hz, 1 Ph
  • Input current – 2 Amps
  • Distance across poles – 0 to 300 mm
  • Magnetic field AC – Constant level, DC-Pulsed, infinitely variable.
  • Lifting power Approx. 27 Kg. at 100mm spacing HWDC mode.
  • Yoke Weight 3.5 Kgs approx.
  • Controls On/Off Switch, AC/DC Switch, DC Field intensity potentiometer
Read more

V3 Phase-Series

, ,
MPI Power Source (Mobile Series) for Prod & CableWrap Method Range - 8,000 Amps to 20,000 Amps
Download TDS
Download Brocture
Contact us for more details
Read more

ZChek F18

, ,

Wet Method Fluorescent Magnetic Particles

ZChek F18 is a Dark Brown Colored Magnetic Particle Powder designed to be fluorescing Bright Yellow- Green under UV Light. ZChek F18 consists of ultra-high sensitivity particles for detection of very fine discontinuities in Ferromagnetic materials. Using the state-of-the-art encapsulation technology, ZChek F18 is manufactured to exhibit excellent properties (High permeability, low retentivity, high mobility and optimum particle distribution) required for high sensitive fluorescent MPI process.
Download TDS
Download MSDS
Batch Certificate
Contact us for more details
Read more

ZC-230 Series

, ,

Standard MPI Bench Equipment

The Magnetic Particle Inspection Equipment ZC 230 is designed and manufactured to deliver 2500 Amps AC / 3000 Amps FWDC. The 1phase FWDC is extremely useful to detect Near surface discontinuities whereas the AC is used to detect Surface discontinuities. Independently controlled contact and coil circuits determines superior indication visibility.
Download TDS
Download Brochure
Contact us for more details
Read more

ZChek F18W

, ,

Water based Fluorescent Magnetic Particle

ZChek F18W is a Brown Colored water based Magnetic Particle Powder designed to be fluorescing Bright Yellow- Green under UV Light. ZChek F18W consists of ultra-high sensitivity particles for detection of very fine discontinuities in Ferromagnetic materials. Using the state-of-the-art encapsulation technology, ZChek F18W is manufactured to exhibit excellent properties (High permeability, low retentivity, high mobility and optimum particle distribution) required for high sensitive fluorescent MPI process. Special additives in F18W provide excellent particle mobility in water medium and avoid flash rusting of parts.
Download TDS
Download MSDS
Batch Certificate
Contact us for more details
Read more

ZChek F9

, ,

Fluorescent Magnetic Particles

ZChek F9 is a Green Colored Magnetic Particle Powder designed to be fluorescing Bright – Green under UV Light. ZChek F9 consists of high sensitivity particles for detection of very fine, medium, and shallow discontinuities in Ferromagnetic materials. Using the state-of-the-art encapsulation technology, ZChek F9 is manufactured to exhibit excellent properties (High permeability, low retentivity, high mobility and optimum particle distribution) required for high sensitive fluorescent MPI process.
Download TDS
Download MSDS
Batch Certificate
Contact us for more details
Read more
